HandySCAN MAX 3D scanners for large components
HandySCAN MAX EVO and MAX EVO Elite are handheld 3D scanning options for large components such as castings, fabrications and heavy-equipment parts. Choose around the complete part dimensions, access and measurement requirement, then validate capture and analysis on a representative assembly.
What can HandySCAN MAX Series help you achieve?
Digitise large components
Capture the geometry of large castings, welded fabrications and assemblies.
Support dimensional control
Use scan data to compare manufactured surfaces with the design in inspection software.
Create engineering references
Document existing large parts for modification and reverse-engineering work.
Application fit
When should you consider HandySCAN MAX Series?
- Large castings and welded fabrications
- Heavy equipment components and assemblies
- Large-part reverse engineering and dimensional checks
Application support from K K Geo System Pvt Ltd
Our team helps you select the scanner model, reference accessories, software and workstation around your components and required output. Share your application so we can recommend a suitable configuration.
HandySCAN MAX Series — models and specifications
| Model | Accuracy | Volumetric accuracy | Measurement resolution |
|---|---|---|---|
| MAX EVO | 0.150 mm | 0.150 mm + 0.020 mm/m | 0.04 mm |
| MAX EVO Elite | 0.075 mm | 0.075 mm + 0.010 mm/m | 0.04 mm |
Both models publish 2,250,000 measurements/s. Acquisition rate describes data capture, not the complete inspection cycle.
Published specifications apply to the manufacturer’s configuration and test conditions.
How does HandySCAN MAX Series fit into your workflow?
Reference preparation and scanning cover the accessible surfaces of the large component. The resulting geometry is processed and aligned for dimensional analysis or reconstruction in the selected engineering software.
Watch HandySCAN MAX Series in action
See the equipment in use
Explore the equipment and its application in this manufacturer overview.
Manufacturer overview · 1:15 · Plays on this page
How is a HandySCAN MAX system priced for an India project?
The quotation for HandySCAN MAX Series depends on the scanner model, reference accessories, software and workstation. K K Geo System Pvt Ltd can recommend a configuration for your application and provide a proposal covering the agreed equipment, training and support.
Your HandySCAN MAX Series questions answered
Which components suit HandySCAN MAX?
Large castings, welded fabrications and heavy-equipment assemblies are typical applications. MAX is intended for component geometry and dimensional measurement; building surveys use a different scanning workflow.
What is the difference between MAX EVO and MAX EVO Elite?
MAX EVO publishes 0.150 mm accuracy and MAX EVO Elite 0.075 mm. Their volumetric accuracy also differs, which matters when measuring across a large component.
Can MAX capture enclosed areas?
The scanning process needs access to the surface. Enclosed areas may require repositioning, disassembly or another measurement method.
Which alternatives should you compare?
Review photogrammetry references · Compare component inspection scanners
Discuss your application
Discuss your HandySCAN MAX Series application
Share your component and measurement requirements so K K Geo System Pvt Ltd can recommend a suitable configuration and arrange a relevant demonstration.
